Learning how to make a stage plot takes about ten minutes and saves you hours of confusion at every gig. A stage plot is a simple top-down diagram showing where each band member stands, what gear they use, and where they need power and monitors. You hand it to the venue or engineer ahead of time so the stage is set up before you arrive.
This guide covers exactly what to put on it, how to lay it out, and the free tools to draw one.
What a stage plot is for
A stage plot answers one question for the engineer: where does everything go? It’s a visual companion to your input list, which handles the channel-by-channel detail. Together they let a venue prep your stage without a single phone call, which is exactly what gets you booked again.
It’s the live-sound equivalent of planning a session before you hit record — like sketching a studio layout so everything has a place before the work starts.
What to include on the plot
Keep it to the essentials. A good stage plot shows:
- Each band member’s position, drawn from the audience’s point of view (so “stage left” is the audience’s right — label it clearly to avoid confusion).
- Their instrument and gear: drum kit, bass rig, guitar amp, keys, vocal mic.
- Monitor positions and whether each player uses a wedge or in-ear monitor.
- Power needs: mark which positions need a power outlet for amps, pedalboards, or keyboards.
- DI and mic needs at each position, if it helps clarify.
- A contact name and number for the band’s point person.
Lay it out clearly
Draw the stage as a rectangle with the audience at the bottom. Place each member where they actually stand and use simple, labelled icons rather than fancy graphics. Add short notes only where needed — for example, “drummer needs power for in-ear pack” or “keys player has own DI.” The goal is something an engineer can read in ten seconds.
Be honest about backline. If you’re bringing your own amps, say so; if you need the venue to provide a kit, mark that clearly. Surprises at load-in are what soundchecks hate, and a clear plot makes the soundcheck dramatically faster.
How to draw one step by step
If you’ve never made a plot before, working through it in order keeps things simple:
- Start with the stage outline. Draw a wide rectangle and write “AUDIENCE” along the bottom edge. Everything else is placed relative to that line, so it’s the reference point that stops left and right getting muddled.
- Drop in the big, fixed pieces first. The drum kit, bass and guitar rigs, and keyboard rig rarely move, so position those before anything else. Most bands put drums centre-rear and spread the rest across the front.
- Add vocal positions and mics. Mark each lead and backing vocal spot. Note if a singer also plays an instrument, since that affects how much room they need.
- Layer on monitors. Show a wedge in front of each position that needs one, or write “IEM” where a player is on in-ears. If your band runs separate monitor sends, number the mixes so the engineer knows how to build each monitor mix.
- Mark power and DI last. Put a small symbol wherever you need a mains outlet, and note any positions supplying their own DI box so the venue doesn’t double up.
- Add the header. Band name, date or “current,” and a contact number go at the top so the page can stand alone if it gets separated from your email.
Keep the visual language consistent. One shape for amps, one for monitors, one for DI boxes — an engineer scanning twenty plots a week will thank you for not reinventing the symbols.
Tools for drawing a stage plot
You don’t need design skills. Common options include:
- Dedicated stage-plot tools with drag-and-drop instrument icons that export a clean PDF.
- Slide software like Google Slides, Keynote, or PowerPoint — drop in shapes and text boxes and export as a PDF.
- Pen and paper, photographed clearly. A neat hand-drawn plot beats no plot at all.
Whatever you use, export to PDF so it looks identical on every device and prints cleanly. Keep the file name obvious, like “BandName-StagePlot.pdf”.
Common mistakes to avoid
Most stage-plot problems come from doing too much rather than too little. Watch out for these:
- Overcrowding the page. If a plot needs a legend the size of a paragraph, it’s trying to be an input list as well. Keep the two documents separate and let each do one job.
- Mislabelling stage sides. This is the single most common error. Decide on the audience’s viewpoint, label both sides in plain words, and stop guessing.
- Leaving it out of date. A plot that still shows last year’s lineup is worse than none, because the engineer will set up the wrong stage with confidence.
- Forgetting power. Pedalboards, in-ear packs, and active DIs all need mains. An unmarked outlet need is the classic cause of a scramble for an extension lead during your set.
- Sending an editable file. A document that reflows on the engineer’s machine can hide or shift items. Always send a flat PDF.
Keep it updated and bring copies
Update the plot whenever your lineup or gear changes — a new member, a switch from wedges to in-ears, an extra keyboard. Email it to the venue a few days before the show along with your input list, and bring a printed copy or two for the engineer on the day. A current, accurate plot marks you as a band that’s easy to work with.
Frequently asked questions
Do small gigs really need a stage plot?
Even at a small bar, a one-page plot speeds up setup and prevents the “where do you want me?” shuffle. For anything with a house engineer or a festival slot it’s close to essential, and it pairs naturally with the rest of setting up sound for a small gig. The effort is tiny and the goodwill is real.
What’s the difference between a stage plot and an input list?
The stage plot is the visual map of who stands where and what they need. The input list is the channel-by-channel list of every signal going to the mixer. Engineers want both — the plot for layout, the list for patching.
Should stage directions be from the band’s or audience’s view?
Conventionally, stage left and stage right are from the performer’s perspective facing the audience, but plenty of confusion comes from this. The safest move is to draw from the audience’s viewpoint and label sides explicitly so there’s no guesswork.
How far ahead should I send the plot?
A few days before the show is the sweet spot — early enough that the engineer can flag any issues with backline or power, but recent enough that it reflects your current lineup. For festivals or multi-band bills, follow whatever advance deadline the organiser sets, since they’re collating plots from everyone.
