Best Pedal Power Supplies

Violet Recording Editorial Team Avatar

·

8 min read

Best Pedal Power Supplies

Power is the least exciting part of a pedalboard and the one most likely to ruin it. A cheap daisy-chain cable can add hum, starve a digital reverb of current, or cause pops when you stomp a switch. The best pedal power supply for your rig is one with enough outputs, enough current (measured in milliamps, mA) for every pedal, and ideally isolated outputs so pedals cannot leak noise into each other. Below are nine supplies across every budget band, from a simple daisy-chain adapter to tour-grade isolated bricks, plus a quick method for working out exactly what your board needs.

Compare our picks at a glance

ProductKey specPrice
9V 1700mA, daisy chain for 8 pedalsCheck price
10 isolated outputs, 9/12/18VCheck price
6 isolated outputs, 9/12/18VCheck price
8 isolated outputs, 9V/12VCheck price
8 isolated 9V outputs, 500mA eachCheck price
9-outlet pedal power supplyCheck price
5-output high-current pedal PSUCheck price
Pedalboard-size isolated powerCheck price
48W pedal power, 4 voltagesCheck price

Isolated vs daisy-chain power

A daisy-chain setup uses one adapter and a cable with several plugs. Every pedal shares the same ground and the same current pool. It is cheap and works fine for a few analog pedals, but mixing digital pedals, high-gain drives and modulation on a shared chain often produces whine, hum or clicking.

An isolated supply gives each output its own transformer-separated circuit, so each pedal behaves as if it had its own battery. That stops ground loops between pedals and keeps one hungry pedal from dragging the others down. For anything beyond three or four pedals, isolation is worth paying for, and it often removes noise that players otherwise try to hide with a gate.

The best pedal power supply picks

Truetone 1 Spot Combo Pack

Truetone 1 Spot Combo Pack
Truetone 1 Spot Combo Pack specifications
SpecificationDetails
TypePedalboard power supply kit
Output9Vdc, 1700mA
CableMulti-Plug 8 daisy-chain
IncludedAdapter and full plug adapter set
Not forDigital multi-effects pedals
Warranty1-year limited

The Truetone 1 Spot Combo Pack is the classic daisy-chain solution: one compact 9V adapter plus a multi-plug cable and converters for odd-sized jacks. It replaces a fistful of wall warts on a small, all-analog board.

Best for: beginners with a handful of simple analog pedals.

  • Pros: very affordable, small, includes adapters for different pedals.
  • Cons: not isolated; can introduce noise with digital or high-gain pedals.

Donner DP-1

Donner DP-1
Donner DP-1 specifications
SpecificationDetails
TypePedal power supply
Outputs10 isolated DC
Voltages9V, 12V or 18V pedals
InputAC 100-240V
ProtectionShort-circuit and overcurrent
Included10 power cables

The Donner DP-1 brings 10 isolated DC outputs to a budget price. It is the most common step up from daisy chains for players who want quieter power without a premium spend.

Best for: budget boards that have outgrown a daisy chain.

  • Pros: ten isolated outputs, low cost, comes with cables.
  • Cons: fewer high-current outputs than premium bricks; check your digital pedals’ draw.

Truetone 1 SPOT Pro CS6

Truetone 1 SPOT Pro CS6
Truetone 1 SPOT Pro CS6 specifications
SpecificationDetails
TypePedalboard power supply
Outputs6 isolated
Voltages2 x 9V/18V, 2 x 9V/12V, 2 x 9V
ProfileLow profile
Current per outputnot stated

The Truetone 1 SPOT Pro CS6 is a low-profile brick with six isolated outputs, including higher-voltage options for pedals that run at 12V or 18V. Its slim height fits under most rail-style boards.

Best for: small and mid-size boards with a mix of analog and digital pedals.

  • Pros: low profile, isolated, flexible voltages.
  • Cons: six outputs fill fast on larger boards.

Voodoo Lab Pedal Power 2 Plus

Voodoo Lab Pedal Power 2 Plus
Voodoo Lab Pedal Power 2 Plus specifications
SpecificationDetails
TypeIsolated pedal power supply
Outputs8 isolated
Current4 x 100 mA, 2 x 250 mA, 2 x 100 mA SAG
Voltage9V, switchable to 12V
RegulationLinear, toroidal transformer
ExtrasAC courtesy outlet, cables included

The Voodoo Lab Pedal Power 2 Plus is the supply that made isolated power mainstream. Its eight isolated outputs include options for vintage-style pedals that like lower voltage, and it has a long reputation for reliability on touring boards.

Best for: mostly analog boards and vintage fuzz lovers.

  • Pros: proven reliability, isolated outputs, sag-style options.
  • Cons: heavier and taller than modern bricks, limited high-current outputs for big digital pedals.

Voodoo Lab Pedal Power X8

Voodoo Lab Pedal Power X8
Voodoo Lab Pedal Power X8 specifications
SpecificationDetails
TypePedal power supply
Outputs8 isolated 9V, up to 500mA each
Input100-240VAC via 12V adapter
IncludedAdapter, pedal cables, 3M Dual Lock
Size5.5 x 2.75 x 1 in

The Voodoo Lab Pedal Power X8 is the high-current modern answer from the same company, designed for boards full of digital delays, reverbs and multi-effects that draw far more than a classic analog pedal.

Best for: digital-heavy boards that need plenty of current per output.

  • Pros: high current per output, isolated, Voodoo Lab build quality.
  • Cons: premium price; more than an analog-only board needs.

Strymon Zuma

Strymon Zuma
Strymon Zuma specifications
SpecificationDetails
TypeGuitar pedal power supply
Outputs9
Voltages9V, 12V, 18V
InputWorldwide power
Current per outputnot stated

The Strymon Zuma is a nine-output, low-noise supply built with power-hungry digital pedals in mind. Every output can handle demanding pedals, which removes the usual puzzle of matching outputs to current draw.

Best for: big boards with several digital pedals.

  • Pros: high current on every output, quiet operation, slim profile.
  • Cons: splurge pricing.

Strymon Ojai

Strymon Ojai
Strymon Ojai specifications
SpecificationDetails
TypePedal power supply
Outputs5
Voltage9V
CurrentHigh current
Isolationnot stated

The Strymon Ojai is a compact five-output high-current supply. Its trick is expandability: you can add more Ojai units later with an expansion kit instead of replacing the whole supply.

Best for: small boards that may grow, or tight spaces under the board.

  • Pros: tiny footprint, high current, expandable.
  • Cons: five outputs per unit; expanding adds cost.

MXR Iso-Brick

MXR Iso-BrickMXR Iso-Brick
MXR Iso-Brick specifications
SpecificationDetails
TypePedal power supply
SizePedalboard-friendly
Package size16.5 x 10.2 x 13.2 cm
Package weight0.885 kg
Outputsnot stated

The MXR Iso-Brick offers ten isolated outputs with a range of voltage and current options, making it a strong value choice for larger mixed boards. If space is tight, the MXR Mini Iso-Brick covers smaller boards.

Best for: mid-size and large boards that need many outputs at a fair price.

  • Pros: lots of isolated outputs, flexible voltages, solid build.
  • Cons: taller than some boards’ clearance allows.

CIOKS DC7

CIOKS DC7
CIOKS DC7 specifications
SpecificationDetails
TypePedal power supply
Topology2-stage switch-mode
Voltages4 selectable per outlet
Total output48W max
Included12 Flex cables
Outputsnot stated

The CIOKS DC7 is a compact, well-regarded isolated supply with seven outputs and flexible voltage options. CIOKS also makes expanders, so it scales up if your board does.

Best for: players who want premium quiet power in a small box.

  • Pros: small, quiet, flexible outputs, expandable system.
  • Cons: premium price for its output count.

Comparison table

Product Best for Key feature
Truetone 1 Spot Combo Pack Small analog boards Daisy chain, very cheap
Donner DP-1 Budget isolation 10 isolated outputs
Truetone 1 SPOT Pro CS6 Small mixed boards Low profile, 6 isolated
Voodoo Lab Pedal Power 2 Plus Analog and vintage Proven isolated design
Voodoo Lab Pedal Power X8 Digital-heavy boards High current
Strymon Zuma Large digital boards High current on all 9 outputs
Strymon Ojai Expandable small boards 5 outputs, chainable
MXR Iso-Brick Value for big boards 10 isolated outputs
CIOKS DC7 Premium compact 7 outputs, expanders

How to choose the best pedal power supply

List every pedal’s voltage and current. Check the manual or the label near the power jack. Most compact analog pedals draw very little (often well under 50mA), while digital reverbs, delays and multi-effects can need several hundred mA. Each output must supply at least what its pedal draws; extra headroom is fine because a pedal only takes what it needs.

Match voltage and polarity. Most pedals use 9V center-negative. Some run at 12V or 18V for more headroom, and a few use unusual plugs or polarity. Never feed a 9V-only pedal a higher voltage, and use the correct polarity cables a supply provides.

Count outputs with room to grow. Two spare outputs saves you from buying a second supply next year.

Check height and mounting. Measure your board’s clearance before buying. Our best pedalboards guide notes which boards suit under-mounting, and the walkthrough on how to build a pedalboard covers routing power cables away from audio cables.

Multi-effects are different. Many floor multi-effects units come with their own adapter and draw more than a pedal supply output can provide. If you run one, as in our best multi-effects pedals roundup, keep its own adapter unless the supply explicitly supports it.

Hum after upgrading? Keep power cables crossing audio cables at right angles, avoid running them in parallel, and check that all your gear shares a properly grounded outlet. If you still hear noise with high gain, a gate from our best noise gate pedals list handles what is left.

A quick worked example

Say your board has a tuner, a compressor, two analog overdrives, a digital delay and a digital reverb. The four analog pedals together may draw well under 200mA, but the two digital pedals could need a few hundred mA each. A cheap daisy chain might technically power everything yet still hum, because the digital pedals share ground with the drives. An isolated supply with at least two high-current outputs solves both problems: a six-output unit such as the Truetone CS6 covers this board exactly, while an eight-output unit such as the Pedal Power X8 leaves room for two more pedals. Write the draw of each pedal on a strip of tape beside its output so future swaps are painless.

FAQ

Do I really need an isolated power supply?

For two or three analog pedals, a daisy chain is often fine. Once you add digital pedals, high-gain drives or more than four or five pedals, isolated outputs usually remove hum and whine that shared power introduces.

Can a supply with more mA damage my pedal?

No. The mA rating is how much current the output can supply, not how much it forces into the pedal. Voltage and polarity are what must match. Too little current is the problem, causing glitches or failure to power on.

Can I run a 9V pedal at 18V for more headroom?

Only if the manufacturer says the pedal supports it. Some drives are designed for 18V operation and gain headroom, but many pedals, especially digital ones, can be damaged by higher voltage.

How do I find out how many mA my pedal draws?

A pedal’s current draw is listed in its manual or printed on the label near the power jack, given in milliamps (mA). Compact analog pedals usually draw very little, while digital reverbs, delays and multi-effects can need several hundred mA, so check every pedal before choosing a supply.

What happens if I plug a pedal in with the wrong polarity?

Reversed polarity can stop a pedal from powering on and can damage some pedals permanently. Most pedals use 9V center-negative, but a few use center-positive plugs, so use the polarity cables supplied with the power supply and check the marking beside the pedal’s jack before connecting.

Can I power a floor multi-effects unit from a pedal power supply?

Usually not. Floor multi-effects units often draw more current than a single pedal supply output can deliver, so keep the unit’s own adapter unless the power supply’s maker explicitly lists support for it. Underpowering a multi-effects unit can cause glitches, reboots or failure to start.

Can I add more outputs to my pedal power supply later?

Some supplies are designed to expand. The Strymon Ojai accepts additional units through an expansion kit, and CIOKS sells expanders for the DC7. Fixed bricks such as the Donner DP-1 cannot grow, so buying a couple of spare outputs up front is the cheaper route for most boards.

Will a noise gate fix hum caused by bad pedal power?

A noise gate can hide hum during pauses but does not remove the cause. Power-related noise is better fixed with isolated outputs, careful cable routing and a properly grounded outlet. A gate is best kept for leftover noise from high-gain drives after the power is sorted.
