So what is a stereo imager, and why does nearly every mixing and mastering chain include one? A stereo imager is a mixing plugin that controls how wide or narrow a sound appears across the left-to-right stereo field. It lets you push elements outward so they feel bigger and more spacious, pull them inward so they sit tight in the centre, or adjust width differently for the bass and the treble. Used with care, it adds depth and separation; used carelessly, it hollows out your mix the moment someone plays it in mono.
Violet Recording is reader-supported — we may earn a commission from links on this page, at no extra cost to you.
What is a stereo imager and how does it work?
To understand what a stereo imager does, it helps to know how stereo sound is actually built. A stereo signal is two channels — left and right. Your ears perceive width from the differences between those two channels: if the left and right are identical, the sound appears dead centre (that is mono). The more they differ, the wider and more spread-out it feels.
Most stereo imagers work using something called Mid/Side (M/S) processing. Instead of treating the signal as left and right, the plugin splits it into two different components: the Mid (everything that is common to both channels — the centre information, like your kick, bass and lead vocal) and the Side (everything that differs between the channels — the stereo, “out to the edges” information). By turning the Side component up, the plugin exaggerates the differences between left and right, and the sound appears wider. Turn the Side down, and the image collapses toward the centre until, at the extreme, it becomes fully mono.
That single idea — adjusting the balance between Mid and Side — is the engine behind almost every widening tool you will meet, whether it is a dedicated imager, a stereo widener knob on a channel strip, or the imaging module inside a mastering suite.
The key controls you will find on an imager
Different plugins dress it up differently, but the useful controls come down to a short list:
- Width (or Stereo Width / Amount): the headline control. At 100% you hear the signal as recorded; below 100% it narrows toward mono; above 100% it widens. This is really just a Side-level control with a friendlier name.
- Multiband width: better imagers split the signal into frequency bands so you can widen the highs while keeping the lows tight. This is the single most important feature to look for, and the reason is explained below.
- Mono / bass frequency: a control that forces everything below a chosen frequency (often 100–200 Hz) back to mono. Almost every good imager has this, and you should almost always use it.
- Rotation / balance: shifts the perceived centre of the image slightly left or right to correct a lopsided mix.
- Correlation meter and goniometer: not controls but displays. The correlation meter reads from +1 (perfectly mono-compatible) down through 0 to −1 (out of phase). The goniometer (or vectorscope) draws the shape of your stereo field so you can see how wide and how balanced it is.
If you are new to the wider world of mix processing, our guide to EQ and compression fundamentals is a good companion — imaging is the third dimension you add once level and tone are under control.
When to use a stereo imager in a mix
Reach for an imager when you want to create space and separation, not as a default on every track. The elements that usually benefit are the ones meant to sound big and ambient: synth pads, backing-vocal stacks, reverb returns, room mics, doubled guitars, and pianos. Widening these lets them wrap around the listener and clears room in the centre for the vocal, kick and bass to punch through.
On a full mix or master, a gentle imager can add a touch of air and openness — but the operative word is gentle. On the mix bus you are adjusting the width of everything at once, so even a small move has a large effect. If you are mastering your own material, our explainer on what mastering is puts imaging in context alongside EQ, compression and loudness.
Equally, know when not to widen. Anything that anchors the song — lead vocal, snare, kick, bass, mono synths — generally wants to stay centred and focused. Widening those doesn’t make them bigger; it smears them and weakens their impact.
Why bass should stay in the centre (mono)
Here is the rule that separates a clean mix from a wobbly one: keep the low end mono. Low frequencies carry a lot of energy, and when you spread them wide you introduce phase differences between left and right. On headphones that might sound impressively huge, but on a club system, a Bluetooth speaker, or any mono playback, those out-of-phase lows partially cancel — and your once-mighty bass suddenly disappears or turns flabby.
This is exactly why multiband imagers exist. Set the low band to 0% width (mono) up to somewhere around 120–150 Hz, keep the mids natural, and reserve any widening for the highs, where phase issues are far less audible and the sense of “air” lives. A rock-solid mono low end with widened highs is the sound of a professional, translatable mix.
Common stereo imager mistakes to avoid
Widening is seductive because more width sounds “better” in isolation. These are the traps that catch beginners:
- Overwidening the whole mix. Cranking width past a modest boost hollows out the centre and makes the mix feel thin and unstable. If it sounds great soloed but weak in the full mix, you have gone too far.
- Ignoring mono compatibility. Always check your mix in mono. Flip a mono button on your monitor controller or master bus and listen: elements that vanish or lose body are being cancelled by phase problems your imager introduced.
- Widening the bass. Covered above — it is the most common and most damaging mistake.
- Widening a genuinely mono source. A widener can only exaggerate stereo information that already exists. On a mono recording there is no Side signal to boost, so some plugins fake it with tricks that create phase problems for no real benefit. To get true width from a mono part, use doubling, panning, a stereo reverb or a chorus instead.
- Not trusting your ears over the meters. The correlation meter is a guide, not a verdict. Dipping briefly below zero on a wide reverb tail is fine; sitting at −1 on your kick is not.
Stereo imager vs panning: what is the difference?
Beginners often mix these up. Panning places a single sound at a specific point between the speakers by adjusting how loud it is in each channel — it moves a mono element left or right. A stereo imager works on an already-stereo signal and changes how spread out it is, not where its centre sits. Panning is placement; imaging is width. You use panning to arrange elements across the field and an imager to control how much of that field a stereo element occupies. They solve different problems, and a good mix uses both.
The best free stereo imager plugins
You don’t need to spend anything to start. A few widely used free imagers cover the essentials:
- Voxengo MSED — a free Mid/Side encoder/decoder that lets you adjust the Mid and Side levels independently. It is a technical, no-frills tool, but it teaches you exactly how M/S width works.
- iZotope Ozone Imager — a free standalone version of the imager from Ozone, with a multiband width control, a stereoize mode and a clear vectorscope. It is one of the most popular free options for good reason.
- Flux Stereo Tool — a long-standing free utility for width, balance and phase adjustment with solid metering.
- TDR Nova / Limiter No6 makers and others — many respected developers give away metering and utility plugins; a free goniometer plus a mono-check tool will take you a long way.
If you are also building out your free toolkit for other jobs, our roundup of the best free synth VSTs and the guide to the best free DAWs for beginners pair well with these.
Where to get a paid stereo imager plugin
Paid imagers add finer multiband control, better metering, mono-maker filters, and sometimes psychoacoustic widening that stays mono-safe. When you are ready to buy, you can browse and compare imagers and full mastering suites at a store like Plugin Boutique, which regularly runs sales and bundles.
If your interest is really in the whole mastering chain rather than a standalone widener, a suite is often the smarter buy — our iZotope Ozone review looks at one that includes a capable imaging module alongside EQ, dynamics and loudness tools. For the surrounding skills, see how to mix vocals and browse the wider mixing and mastering hub for related guides.
Frequently asked questions
Does a stereo imager work on mono tracks?
Not really. An imager can only widen stereo information that already exists in the signal, and a mono track has none. Some plugins offer a “stereoize” mode that synthesises fake width, but it can create phase problems. For real width on a mono part, use doubling, hard panning, a stereo reverb, or a chorus instead.
Should I put a stereo imager on the master bus?
You can, but use it sparingly. On the master you are widening everything at once, so tiny moves go a long way. Keep the low band mono, apply only a subtle high-frequency widen, and always check the result in mono to make sure nothing collapses or loses punch.
What is a good correlation meter reading?
Aim to stay mostly in positive territory, near +1 for centred, mono-heavy material like kick and bass. Wide stereo elements will naturally read lower and can dip toward zero on reverb tails without a problem. Sustained readings at −1 signal a phase issue you should fix before it wrecks your mono playback.
