The arpeggiator in Logic Pro is a MIDI effect that turns a held chord into a stream of individual notes, played in whatever order and speed you choose. To use it, add the Arpeggiator to a software instrument track’s MIDI FX slot, hold a chord, and the plugin plays the notes one at a time in sync with your project tempo. That’s the whole idea — you supply the harmony, it supplies the movement.
Violet Recording is reader-supported — we may earn a commission from links on this page, at no extra cost to you.
Below is the full walkthrough: how to add it, how to shape the pattern with note order, rate and octave range, how latch and the advanced panels work, and the mistakes that make people think it’s broken when it isn’t. Everything here uses Logic’s stock Arpeggiator, so there’s nothing extra to buy to follow along.
What the Arpeggiator actually is in Logic Pro
The Arpeggiator is one of Logic Pro’s MIDI FX (also called MIDI plugins), not an audio effect. That distinction matters. Audio effects like EQ and reverb process sound after your instrument has made it. MIDI FX sit before the instrument and change the note data going into it. The Arpeggiator takes the chord you’re holding and rewrites it, on the fly, into a repeating sequence of single notes.
Because it only touches MIDI, it works on software instrument tracks — the ones running a Logic synth or sampler such as Alchemy, ES2, Sampler or Vintage instruments. It will not do anything on an audio track, an external MIDI track’s monitored audio, or a recorded vocal, because there’s no MIDI note stream for it to arpeggiate. If you’re new to how instruments and plugins fit together, our explainer on what a VST is gives useful background, though Logic’s own plugins use the Audio Units format rather than VST.
How to add the arpeggiator in Logic to a software instrument
Getting the arpeggiator in Logic onto a track takes a few seconds once you know where the slot lives. Follow these steps in order:
- Create or select a software instrument track and load an instrument you can hear when you play — a pad, synth or piano works well for hearing every note.
- Open the Mixer or the channel strip in the Inspector on the left. At the very top of the channel strip, above the instrument slot, is the MIDI FX slot. It sits between the Setting menu and the instrument.
- Click the MIDI FX slot and choose Arpeggiator from the menu. The plugin window opens automatically.
- Hold down a chord on your MIDI keyboard, or draw a sustained chord in the Piano Roll and press play. You should immediately hear the notes broken apart into a pattern.
If you don’t have a hardware keyboard, open Logic’s Musical Typing (Command-K) and hold a few letter keys together — the Arpeggiator responds to those exactly like it responds to real keys. No sound at all? Jump to the troubleshooting section further down; it’s almost always one of two things.
Setting note order, rate and octave range
Once notes are flowing, three controls do most of the shaping. They live across the top and centre of the plugin window.
Note Order decides the direction the arpeggio moves through your chord. The buttons cover the classics — Up, Down, Up and Down, Outside-In, Random, and an “as played” option that follows the order you pressed the keys. Up and Down are the safe, musical defaults; Random is great for generative, evolving textures. There’s usually a Variation control nearby that offers alternate takes on each direction, so it’s worth clicking through those to find movement you like.
Rate sets how fast the notes fire, expressed as a note value — 1/8, 1/16, 1/4 and so on. This is locked to your project tempo, so an arpeggio at 1/16 speeds up and slows down with the song. Many versions let you switch a rate between straight, triplet and dotted feels; start at 1/8 or 1/16 and adjust from there. Because everything is tempo-linked, it’s worth having your project tempo settled first — if you’re matching an existing track, our free audio tools include a BPM finder to nail the tempo before you start programming.
Octave Range stretches the pattern across more than one octave. Set it to 2, 3 or 4 and the arpeggiator repeats your chord shape up the keyboard, which is what gives trance and synth-pop arpeggios that rising, cascading feel. One octave keeps things tight and grounded; higher settings sound bigger and busier.
Using latch, patterns and the advanced panels
Latch is the feature people miss most. Switch Latch on and the arpeggiator keeps playing your chord after you lift your fingers, so you can let a pattern run while you tweak knobs or reach for the mouse. Play a new chord and it takes over. There’s typically a Latch Mode option — the default holds and replaces chords, while other modes let new notes add to or transpose what’s already sounding. If your arpeggio won’t stop, Latch being on is the reason; turn it off to return to normal hold-to-play behaviour.
Beyond the main controls, the Arpeggiator has a row of panels — commonly labelled Note Order, Pattern, Options, Keyboard and Grid — that open deeper editing. The exact layout and names shift a little between Logic versions, but the ideas are consistent:
- Pattern / Grid lets you build a custom step sequence, muting steps, tying notes and setting a cycle length so the arpeggio plays a rhythmic figure rather than a straight run.
- Options controls things like note length (how legato or staccato each note is) and velocity behaviour, including randomisation for a more human feel.
- Keyboard handles latch modes and how held keys map to the pattern.
You don’t need any of these to get a great result — the top-level Note Order, Rate, Octave Range and Latch cover most tracks. The panels are there when you want a signature rhythm rather than a generic up-down run. A short arpeggio loop like this is often the seed of a whole song; if you want to build an original track around an idea you’ve programmed, Solmi is one route for turning a musical starting point into a finished piece.
Making the arpeggio permanent
Because the Arpeggiator generates notes live, the pattern only exists while the plugin is running — your Piano Roll still just shows the plain chord. That’s usually fine; you keep full control and can change the pattern anytime. When you’re ready to commit, the reliable way to lock it in is to bounce the track to audio (or bounce in place), which prints exactly what you hear, arpeggiation and all. Keep a copy of the MIDI track so you can go back and re-program if the arrangement changes. Logic doesn’t offer a simple one-click way to convert MIDI FX output back into editable MIDI notes, so bouncing to audio is the dependable method rather than any hidden convert command.
Common problems and quick fixes
Most Arpeggiator trouble comes down to a handful of causes. Run through these before assuming something’s wrong:
- No sound at all. Check you’re on a software instrument track with an instrument loaded, and that you’re holding a chord — the arpeggiator needs at least two notes to have something to sequence, and needs you to actually sustain them.
- Only one note plays. You’re likely pressing keys one at a time. Hold the whole chord down together so the plugin has all the notes to work through.
- It won’t stop playing. Latch is on. Turn it off, or press the same chord again to reset it.
- Timing feels off or drifts. The Rate is tempo-synced, so confirm your project tempo is correct and that the instrument itself doesn’t have a slow attack softening the rhythm.
- Notes sound cut off or overlapping. Adjust note length in the Options panel — too short sounds clipped, too long makes fast rates smear together.
Once the basics behave, the Arpeggiator becomes one of the fastest ways to add motion to a static chord progression. For more on building parts and arranging them, browse the Home Studio Setup hub, and if you’re still choosing software, our guide to the best free DAWs for beginners is a good next read. Producers moving arpeggiated parts into a full mix will also find our walkthrough on how to mix vocals useful once the arrangement comes together.
Frequently asked questions
Does the arpeggiator work on any Logic track?
No. It only works on software instrument tracks, because it processes MIDI note data before the instrument plays it. Audio tracks — recorded vocals, guitars, drums — have no MIDI stream for the plugin to arpeggiate, so the Arpeggiator won’t appear as an option or do anything on them.
Why does my arpeggio keep playing after I let go of the keys?
Latch is switched on. Latch is designed to hold the pattern going so you can adjust settings hands-free, and it catches a lot of first-time users out. Turn Latch off in the plugin window and the arpeggiator will only play while you’re holding a chord.
Can I change the arpeggiator speed to match my song?
Yes — the Rate control is set in note values and follows your project tempo automatically, so the arpeggio always stays in time. Change the note value (say from 1/8 to 1/16) to make it busier or sparser, and set your project tempo before programming so everything lines up.
